Performance
Type IP security camera
Placement supported Indoor & outdoor
Connectivity technology Wired
PTZ control
Tour recording
Preset points
Wide Dynamic Range (WDR)
Day/night mode
Infrared (IR) cut-off filter
Number of languages 11
Languages support Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Portuguese, Russian
Certification EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, KCC KN32 Class A, KN35, IEC/EN/UL 60950-1, EN 50121-4, IEC 62236-4, IEC/EN/UL 60950-22, IEC/EN/UL 62368–1, IEC/EN 60529 IP66/IP67, NEMA TS 2 (Subsection 2.2. 7-2.2. 9), IEC 62262 IK10, ISO 4892-2, EN 50121-4, IEC 62236-4, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-60, IEC 60068-2-78, NEMA 250 Type 4X, NIST SP500-267, EN 60950-1, GS, UL, cUL, CE, FCC, VCCI, CB, KCC, UL-AR
Design
Form factor Dome
Mounting type Ceiling/wall
Product colour Black, White
Housing material Aluminium, Polycarbonate
International Protection (IP) code IP66, IP67
IK code IK10
Fog proof
Camera
Camera pan control
Camera tilt control
Minimum illumination 0.002 lx
Viewing angle, horizontal 63.8°
Viewing angle, vertical 38°
Tilt angle range 0 - 220°
Tilt speed 450 °/sec
Pan range 0 - 360°
Pan speed 450 °/sec
Camera shutter speed 1/11000 - 1/3 s
Image sensor
Sensor type CMOS
Number of sensors 1
Optical sensor size 25.4 / 2.8 mm (1 / 2.8 )
Progressive scan
Lens system
Number of lenses 1
Zoom capability
Optical zoom 30x
Digital zoom 12x
Auto focus
Maximum aperture number 4.2
Minimum aperture number 1.6
Focal length range 4.25 - 127.5 mm
Video
Maximum resolution 1280 x 720 pixels
Video compression formats AVC, H. 264, H. 265, HEVC, M-JPEG, MPEG4
Supported graphics resolutions 320 x 180,1280 x 720 (HD 720)
Supported video modes 720p
Frame rate 60 fps
Video streaming
Image quality adjustment Brightness, Colour depth, Sharpness
Privacy masking
Text caption overlay
Bit rate control Variable Bit Rate (VBR)
Back Light Compensation (BLC)
Network
Ethernet LAN
Ethernet interface type Fast Ethernet
Networking standards IEEE 802.1x, IEEE 802.3at
Supported network protocols IPv4, IPv6 USGv6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, NTCIP, LLDP
Quality of Service (QoS) support
Streaming method Multicast
Storage
Card reader integrated
Compatible memory cards SD, SDHC, SDXC
Flash memory 512 MB
Internal memory 1024 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
Security
Password protection
Video motion detection
IP address filtering
HTTPS encryption
Alert notification type E-mail
Intelligent Video Surveillance (IVS) system features Missing object, Tripwire
Power
Power source type AC, PoE
AC input voltage 100-240 V
Power consumption (typical) 14 W
Power consumption (max) 51 W
Operational conditions
Storage temperature (T-T) -40 - 65 °C
Operating relative humidity (H-H) 10 - 100%
Weight & dimensions
Width 232 mm
Depth 232 mm
Height 269 mm
Weight 3.75 kg
Packaging content
Number of cameras 1
Sun shield included
Manual
